C+CARRIER / L-4S (Smooth)
Long life and low wear with special tread and mixture
OVERVIEW
C+CARRIER SMOOTH (L-4S)
Smooth treaded tire for port applications. Optimized tread compound
offers outstanding resistance to wear and ensures exceptional longevity.
Promises high stability thanks to its smooth tread design. Highly resistant
to abrasion.
PROPERTIES
TIRE SECTION
ALL SIZES
C+CARRIER / L-4S (Smooth)
| TIRE SIZE | PR | TT/TL | LOAD INDEX | SPEED SYMBOL | RIM | INFLATED DIMENSIONS (NO LOAD) | INFLATED DIMENSIONS (W/LOAD) | TREAD DEPTH(MM) | INFLATING PRESSURE (psi/bar) | LOAD CAPACITY PER TIRE (KG) | LOAD CAPACITY PER TIRE (KG) | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| RECOM. (INCHES) | PERMITTED (INCHES) | Section Width Min-Max | OUTER DIAMETER (MM) | DYNAMIC RADIUS CIRCLE (MM) | STATIC LOADED RADIUS (MM) | OFF ROAD PURPOSES | HARD IMPROVED SURFACE | |||||||||||
| STATIC | 10 KM/H ** | 25 KM/H | STATIC | 5 KM/H | 10 KM/H ** | |||||||||||||
| 18.00-25 | 40 | TL | 206 | A2 | 13.00/2.5 | 13.00(2.5 IF (2) ; 15.00/2.5 | 498 | 1673 | 4852 | 743 | - | 137 | 27200 | 17000 | 14450 | 30600 | 24650 | 22950 |
