PC / 1
Compactor Tire
OVERVIEW
PC-1
Suitable for industrial compacting roadbeds and rolling asphalt. Heat
resistant smooth pattern design distributes the pressure equally on the
road. Delivers high mileage performance and comfort riding.
PROPERTIES
TIRE SECTION
ALL SIZES
PC / 1
| TIRE SIZE | PR | TT/TL | LOAD INDEX | SPEED SYMBOL | RIM | INFLATED DIMENSIONS (NO LOAD) | INFLATED DIMENSIONS (W/LOAD) | TREAD DEPTH(MM) | INFLATING PRESSURE (psi/bar) | LOAD CAPACITY PER TIRE (KG) | LOAD CAPACITY PER TIRE (KG) | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| RECOM. (INCHES) | PERMITTED (INCHES) | Section Width Min-Max | OUTER DIAMETER (MM) | DYNAMIC RADIUS CIRCLE (MM) | STATIC LOADED RADIUS (MM) | OFF ROAD PURPOSES | HARD IMPROVED SURFACE | |||||||||||
| STATIC | 10 KM/H ** | 25 KM/H | STATIC | 5 KM/H | 10 KM/H ** | |||||||||||||
| 11.0-20 | 14 | TT | 165 | A2 | 9.0,9.00V | 8.0V,8.5,10.0 | 326 | 1048 | 3039 | 476 | - | 94 | 5120 | |||||
| 13.0/80R20 | - | TL | 164 | A3 | 8.0,B8.0,8.0V | 7.33V,7.5,B7.5,7.5V,8.37V | 291 | 1070 | 3103 | 785 | - | 131 | 5000 | |||||
