Developed for loader applications. Delivers optimized performance on all terrains. The special compound and aggressive design of the tread pattern enhances handling throughout its exceptionally long life. Provides outstanding resistance to cuts and wears.
Provides outstanding resistance to cuts and wears.
Specifically designed to offer ultimate performance when excellent traction is needed.
| MANUFACTURER CODE | TIRE SIZE | PR | TT/TL | LOAD / SPEED INDEX | RIM | INFLATED DIMENSIONS (NO LOAD) | INFLATED DIMENSIONS (W/ LOAD) | INFLATING PRESSURE (psi) | LOAD CAPACITY PER TIRE (KG) | ||||||||
| OFF ROAD PURPOSES | HARD IMPROVED SURFACE | ||||||||||||||||
| RECOM. (INCHES) | PERMITTED (INCHES) | OUTER DIAMETER (MM) | SECTION WIDTH MIN-MAX | STATIC LOADED RADIUS (MM) | DYNAMIC ROLLING CIRCUMFERENCE (MM) | SPEED (KM/H) | |||||||||||
| STATIC | 10 | 25 | STATIC | 5 | 10 | ||||||||||||
| 7804 | 15.5-25 | 12 | TL | 168 / A2 | 12.00/1.3 | 12.00/1.3 (DC)(1) | 1277 | 394 | 581 | 3703 | 58 | 8960 | 5600 | 4760 | 10080 | 8120 | 7560 |
| MANUFACTURER CODE | TIRE SIZE | PR | TT/TL | LOAD / SPEED INDEX | RIM | INFLATED DIMENSIONS (NO LOAD) | INFLATED DIMENSIONS (W/ LOAD) | INFLATING PRESSURE (psi) | LOAD CAPACITY PER TIRE (KG) | ||||||||
| OFF ROAD PURPOSES | HARD IMPROVED SURFACE | ||||||||||||||||
| RECOM. (INCHES) | PERMITTED (INCHES) | OUTER DIAMETER (MM) | SECTION WIDTH MIN-MAX | STATIC LOADED RADIUS (MM) | DYNAMIC ROLLING CIRCUMFERENCE (MM)) | SPEED (KM/H) | |||||||||||
| STATIC | 10 | 25 | STATIC | 5 | 10 | ||||||||||||
| 7812 | 17.5-25 | 16 | TL | 177 / A2 | 14.00/1.5 | 14.00/1.3 (1) ; 13.00/1.4 (DC) | 1348 | 445 | 610 | 3909 | 69 | 11680 | 7300 | 6205 | 13140 | 10585 | 9855 |
| 7814 | 17.5-25 | 20 | TL | 181 / A2 | 14.00/1.5 | 14.00/1.3 (1) ; 13.00/1.4 (DC) | 1348 | 445 | 610 | 3909 | 83 | 13200 | 8250 | 7010 | 14850 | 11960 | 11135 |
| MANUFACTURER CODE | TIRE SIZE | PR | TT/TL | LOAD / SPEED INDEX | RIM | INFLATED DIMENSIONS (NO LOAD) | INFLATED DIMENSIONS (W/ LOAD) | INFLATING PRESSURE (psi) | LOAD CAPACITY PER TIRE (KG) | ||||||||
| OFF ROAD PURPOSES | HARD IMPROVED SURFACE | ||||||||||||||||
| RECOM. (INCHES) | PERMITTED (INCHES) | OUTER DIAMETER (MM) | SECTION WIDTH MIN-MAX | STATIC LOADED RADIUS (MM) | DYNAMIC ROLLING CIRCUMFERENCE (MM) | SPEED (KM/H) | |||||||||||
| STATIC | 10 | 25 | STATIC | 5 | 10 | ||||||||||||
| 7822 | 20.5-25 | 20 | TL | 186 / A2 | 17.00/2.0 | 17.00/2.0 IF (2) | 1492 | 520 | 669 | 4327 | 65 | 15200 | 9500 | 8075 | 17100 | 13775 | 12825 |
| MANUFACTURER CODE | TIRE SIZE | PR | TT/TL | LOAD / SPEED INDEX | RIM | INFLATED DIMENSIONS (NO LOAD) | INFLATED DIMENSIONS (W/ LOAD) | INFLATING PRESSURE (psi) | LOAD CAPACITY PER TIRE (KG) | ||||||||
| OFF ROAD PURPOSES | HARD IMPROVED SURFACE | ||||||||||||||||
| RECOM. (INCHES) | PERMITTED (INCHES) | OUTER DIAMETER (MM) | SECTION WIDTH MIN-MAX | STATIC LOADED RADIUS (MM) | DYNAMIC ROLLING CIRCUMFERENCE (MM) | SPEED (KM/H) | |||||||||||
| STATIC | 10 | 25 | STATIC | 5 | 10 | ||||||||||||
| 7832 | 23.5-25 | 20 | TL | 191 / A2 | 19.50/2.5 | 19.50/2.5 IF (2) | 1617 | 597 | 720 | 4689 | 54 | 17440 | 10900 | 9265 | 19620 | 15805 | 14715 |
| 7834 | 23.5-25 | 24 | TL | 196 / A2 | 19.50/2.5 | 19.50/2.5 IF (2) | 1617 | 597 | 720 | 4689 | 69 | 20000 | 12500 | 10625 | 22500 | 18125 | 16875 |
| MANUFACTURER CODE | TIRE SIZE | PR | TT/TL | LOAD / SPEED INDEX | RIM | INFLATED DIMENSIONS (NO LOAD) | INFLATED DIMENSIONS (W/ LOAD) | INFLATING PRESSURE (psi) | LOAD CAPACITY PER TIRE (KG) | ||||||||
| OFF ROAD PURPOSES | HARD IMPROVED SURFACE | ||||||||||||||||
| RECOM. (INCHES) | PERMITTED (INCHES) | OUTER DIAMETER (MM) | SECTION WIDTH MIN-MAX | STATIC LOADED RADIUS (MM) | DYNAMIC ROLLING CIRCUMFERENCE (MM) | SPEED (KM/H) | |||||||||||
| STATIC | 10 | 25 | STATIC | 5 | 10 | ||||||||||||
| 7847 | 26.5-25 | 28 | TL | 203 / A2 | 22.00/3.0 | 22.00/3.0 IF (2) | 1750 | 673 | 775 | 5075 | 69 | 24800 | 15500 | 13175 | 27900 | 22475 | 20925 |
| 7849 | 26.5-25 | 32 | TL | 206 / A2 | 22.00/3.0 | 22.00/3.0 IF (2) | 1750 | 673 | 775 | 5075 | 80 | 27200 | 17000 | 14450 | 30600 | 24650 | 22950 |
| MANUFACTURER CODE | TIRE SIZE | PR | TT/TL | LOAD / SPEED INDEX | RIM | INFLATED DIMENSIONS (NO LOAD) | INFLATED DIMENSIONS (W/ LOAD) | INFLATING PRESSURE (psi) | LOAD CAPACITY PER TIRE (KG) | ||||||||
| OFF ROAD PURPOSES | HARD IMPROVED SURFACE | ||||||||||||||||
| RECOM. (INCHES) | PERMITTED (INCHES) | OUTER DIAMETER (MM) | SECTION WIDTH MIN-MAX | STATIC LOADED RADIUS (MM) | DYNAMIC ROLLING CIRCUMFERENCE (MM) | SPEED (KM/H) | |||||||||||
| STATIC | 10 | 25 | STATIC | 5 | 10 | ||||||||||||
| 7864 | 29.5-25 | 28 | TL | 207 / A2 | 25.00/3.5 | 25.00/3.5 IF (2) | 1873 | 750 | 825 | 5432 | 62 | 28000 | 17500 | 14875 | 31500 | 25375 | 23625 |
| 7866 | 29.5-25 | 32 | TL | 210 / A2 | 25.00/3.5 | 25.00/3.5 IF (2) | 1873 | 750 | 825 | 5432 | 69 | 30400 | 19000 | 16150 | 34200 | 27550 | 25650 |
