Agricultural Tires

TD16

The front tractor tire, designed for 2WD tractors, is suitable for both field operations and short-distance road tasks. This particular model stands out as an excellent choice in the category of tractor front tires.

Agricultural Tires | TD16
TD16

TECHNICAL HIGHLIGHTS

  • Offers long life thanks to its wear-resistant tread compound.

  • Durable shoulders protect the tire effectively by increasing its resistance to any kind of damage.

  • Special tread design keeps the tread free of mud.

TD16

ALL SIZES Agricultural Tires

MANUFACTURER CODE TIRE SIZE PR TT/TL LOAD / SPEED INDEX RIMS INFLATED DIMENSIONS (NO LOAD) INFLATED DIMENSIONS (W/LOAD)
RECOMMENDED (INCH) PERMITTED (INCH) OUTER DIAMETER (MM) SECTION WIDTH (MM) STATIC LOADED RADIUS (MM) DYNAMIC ROLLING CIRCUMFERENCE (MM)
5060 5.50-16 6 TT 86 / A6 4.00E 3.50D, 4.50E 710 150 329 2130
MANUFACTURER CODE TIRE SIZE PR TT/TL LOAD / SPEED INDEX RIMS INFLATED DIMENSIONS (NO LOAD) INFLATED DIMENSIONS (W/LOAD)
RECOMMENDED (INCH) PERMITTED (INCH) OUTER DIAMETER (MM) SECTION WIDTH (MM) STATIC LOADED RADIUS (MM) DYNAMIC ROLLING CIRCUMFERENCE (MM)
5120 6.00-16 6 TT 86 / A6 4.50E 4.00E, 5.00F 735 165 338 2205
MANUFACTURER CODE TIRE SIZE PR TT/TL LOAD / SPEED INDEX RIMS INFLATED DIMENSIONS (NO LOAD) INFLATED DIMENSIONS (W/LOAD)
RECOMMENDED (INCH) PERMITTED (INCH) OUTER DIAMETER (MM) SECTION WIDTH (MM) STATIC LOADED RADIUS (MM) DYNAMIC ROLLING CIRCUMFERENCE (MM)
5170 6.50-16 6 TT 91 / A6 4.50E 4.00E, 5K, 5.50F, 5.50F 760 175 350 2280
5175 6.50-16 8 TT 97 / A6 4.50E 4.00E, 5K,5.50F, 5.50F 760 175 350 2280
MANUFACTURER CODE TIRE SIZE PR TT/TL LOAD / SPEED INDEX RIMS INFLATED DIMENSIONS (NO LOAD) INFLATED DIMENSIONS (W/LOAD)
RECOMMENDED (INCH) PERMITTED (INCH) OUTER DIAMETER (MM) SECTION WIDTH (MM) STATIC LOADED RADIUS (MM) DYNAMIC ROLLING CIRCUMFERENCE (MM)
5230 7.50-16 6 TT 98 / A6 5.50F 5.00F, 5K, 6.00F 805 205 367 2415
5240 7.50-16 8 TT 103 / A6 5.50F 5.00F, 5K, 6.00F 805 205 367 2415
MANUFACTURER CODE TIRE SIZE PR TT/TL LOAD / SPEED INDEX RIMS INFLATED DIMENSIONS (NO LOAD) INFLATED DIMENSIONS (W/LOAD)
RECOMMENDED (INCH) PERMITTED (INCH) OUTER DIAMETER (MM) SECTION WIDTH (MM) STATIC LOADED RADIUS (MM) DYNAMIC ROLLING CIRCUMFERENCE (MM)
5550 6.00-19 6 TT 93 / A6 4.50E 4.00E, 5.00F 814 165 378 2442
MANUFACTURER CODE TIRE SIZE PR TT/TL LOAD / SPEED INDEX RIMS INFLATED DIMENSIONS (NO LOAD) INFLATED DIMENSIONS (W/LOAD)
RECOMMENDED (INCH) PERMITTED (INCH) OUTER DIAMETER (MM) SECTION WIDTH (MM) STATIC LOADED RADIUS (MM) DYNAMIC ROLLING CIRCUMFERENCE (MM)
5580 6.50-20 8 TT 108 / A6 5.00F 4.00E, 5.50F 865 165 402 2595
5582 6.50-20 10 TT 115 / A6 5.00F 4.00E, 5.50F 865 165 402 2595
MANUFACTURER CODE TIRE SIZE PR TT/TL LOAD / SPEED INDEX RIMS INFLATED DIMENSIONS (NO LOAD) INFLATED DIMENSIONS (W/LOAD)
RECOMMENDED (INCH) PERMITTED (INCH) OUTER DIAMETER (MM) SECTION WIDTH (MM) STATIC LOADED RADIUS (MM) DYNAMIC ROLLING CIRCUMFERENCE (MM)
5590 7.50-20 8 TT 108 / A6 5.50F 5.00F 915 214 420 2727
5592 7.50-20 10 TT 115/A6 5.50F 5.00F 915 214 420 2727
INFLATION PRESSURE (PSI/BAR) LOAD CAPACITY PER TIRE, KG
SPEED (KM/H)
10 15 20 25 30 40
45 / 3,1 745 710 670 570 495 395
49 / 3,4 775 735 695 595 515 415
54 / 3,7 795 760 715 610 530 425
41 / 2,8 775 735 695 595 515 410
45 / 3,1 825 790 745 635 550 440
48 / 3,3 840 800 755 645 560 450
38 / 2,6 850 810 765 650 565 450
42 / 2,9 915 875 825 705 610 485
45 / 3,1 925 880 830 710 615 495
52 / 3,6 1005 960 905 770 670 535
57 / 3,9 1050 1000 945 805 700 560
61 / 4,2 1095 1045 985 840 730 585
35 / 2,4 1050 100 945 805 700 560
38 / 2,6 1095 1045 985 840 730 585
41 / 2,8 1125 1075 1015 865 750 600
45 / 3,1 1210 1150 1085 925 805 645
49 / 3,4 1275 1215 1150 980 850 680
54 / 3,7 1315 1250 1180 1005 875 700
41 / 2,8 900 860 810 690 600 480
45 / 3,1 955 910 860 730 635 510
48 / 3,3 975 930 880 750 650 520
45 / 3,1 1395 1330 1255 1070 930 745
49 / 3,4 1455 1385 1310 1115 970 775
54 / 3,7 1500 1430 1350 1150 1000 800
54 / 3,7 1660 1580 1490 1270 1155 885
58 / 4,0 1730 1650 1560 1325 1185 925
62 / 4,3 1820 1735 1640 1400 1215 970
42 / 2,9 1380 1315 1245 1060 920 735
45 / 3,1 1440 1375 1295 1105 960 770
49 / 3,4 1500 1430 1350 1150 1000 800
49 / 3,4 1660 1580 1490 1270 1105 885
54 / 3,7 1730 1650 1560 1325 1155 925
58 / 4.0 1820 1735 1640 1400 1215 970

DOWNLOAD

TD16
